60 GALLON REPLACEMENT FUEL TANK FOR 1999-2007 FORD POWERSTROKE 7.3L, 6.0L CREW CAB SHORT BED
This tank holds approximately 60 gallons of fuel. The float's empty position in the S&B Tank is the same as the OEM tank. Since the bottom surface area on the S&B Tank is larger, the 60 Gallon tank with have a greater fuel reserve.
If your truck has the V shaped crossmember connected to the carrier bearing crossmember(see important note in instructions), the S&B Tank will not fit with this in place.
Do you have an Auxiliary Fuel Tank? Read why using these with our tanks will void the Lifetime Warranty.
If your truck has the V shaped crossmember connected to the carrier bearing crossmember(see important note in instructions), the S&B Tank will not fit with this in place.
S&B Sump Fittings/Drain Plug fittings are required when using our sump feed/return port or after drilling out the bottom port to use as a drain. Fittings are under related products.
Do you have an Auxiliary Fuel Tank? Read why using these with our tanks will void the Lifetime Warranty.
| YEAR | MAKE | MODEL | ENGINE |
| 1999-2003 | FORD | F-250 | 7.3L, DIESEL |
| 1999-2003 | FORD | F-350 | 7.3L, DIESEL |
| 2004-2007 | FORD | F-250 | 6.0L, DIESEL |
| 2004-2007 | FORD | F-350 |
6.0L, DIESEL |
| COMPATIBLE WITH GOOSENECK AND 5TH WHEEL | YES |
| COMPATIBLE WITH OE SKID PLATE | NO |
| DIMENSIONS | 79" X 17.37" X 19.37" |
| DRAIN | YES |
| EMBEDDED FITTING THREAD SIZE | 1/2" NPT |
| GROUND CLEARANCE COMPARE TO OE TANK | 2.9" LOWER THAN STOCK. |
| OEM CAPACITY | 29 GALLONS |
| SENDING UNIT | OE |
| STRAPS INCLUDED | YES |
| SUMP | YES |
| S&B CAPACITY (APPROXIMATE) | 60 GALLONS |
| TANK TYPE | MIDSHIP |
| TRANSFER PUMP READY | YES |
| WEIGHT DRY | 45LBS |
